Steel Slag Process Production Line

Product Specification:
Production Capacity:
Application Fields:
Description

Steel slag treatment production line is our company according to the nature of waste steel slag and carefully match the production line, because the waste steel slag belongs to a kind of industrial waste, unreasonable treatment is bound to cause pollution to the environment, steel slag treatment production line of the necessary equipment is ball mill, in which steel slag ball mill is a kind of grinding equipment with strong applicability.

Steel slag treatment production line can recover part of the metal in steel slag, and some enterprises also use steel slag in cement production.

Picture of steel slag treatment line4dc24ff414911d052a9d5f2edf4ef15e.jpg

If you want to know more about the steel slag treatment production line, welcome to Henan Hongke Heavy Industry Co., Ltd., the steel slag ball mill manufacturer, for consultation and communication, we will certainly help you to make you have greater harvest and development in this field!

The steel slag treatment production line can be divided into two configurations:

1、 Steel slag processing to 60-120 mesh

Steel slag raw material, jaw crusher, fine crusher, belt conveyor, vibrating screen, ball mill, finished product.

Detailed process introduction: the vibrating feeder evenly and quantitatively sends the waste steel slag into the jaw crusher for the first stage crushing. After that, the steel slag is crushed by the fine crusher, and the particle size of steel slag is generally less than 5mm. Through the permanent magnet roller belt conveyor, part of the iron is removed. The crushed materials are graded and screened by vibrating screen. Those that do not meet the requirements of particle size are grinded in the ball mill. The processed products are graded and screened again, and then transported to the finished product area by the belt conveyor.

Process flow chart of steel slag treatment production line

2、 The steel slag is processed to 200 mesh or 325 mesh

Steel slag raw material, jaw crusher, fine crusher, belt conveyor, vibrating screen, dryer, ball mill, finished product.

Detailed process introduction: the vibrating feeder evenly and quantitatively sends the waste steel slag into the jaw crusher for the first stage crushing. After that, the steel slag is crushed by the fine crusher, and the particle size of steel slag is generally less than 5mm. Through the permanent magnet roller belt conveyor, part of the iron is removed, and the crushed materials are graded and screened through the vibrating screen. If the moisture content of the material is more than 3%, it needs to be dried by a dryer. If the material does not meet the requirements of particle size, it will be grinded in the ball mill. The processed products will be graded and screened again, and then transported to the finished product area by the belt conveyor.


The above-mentioned steel slag treatment production line and equipment configuration are not general. The steps can be added and omitted according to the actual situation. If you have any questions about the steel slag treatment production line, you can consult and understand.

Working principle of steel slag treatment production line

The steel slag ball mill is composed of horizontal cylinder, feeding and discharging hollow shaft, grinding head and other parts. The cylinder is a long cylinder with grinding body. The cylinder is made of steel and fixed with steel lining plate. The grinding body is generally made of steel, and is loaded into the cylinder according to different diameter and certain proportion. The grinding body can also be selected according to the particle size of the grinding material, and the material is grinded by grinding The hollow shaft at the feeding end of the mill is put into the cylinder. When the steel slag ball mill cylinder rotates, the grinding body is taken away by the cylinder due to the inertia, centrifugal force and friction force. When it is brought to a certain height, it is thrown down due to its own gravity, and the falling grinding body smashes the materials in the cylinder like a projectile.

Performance characteristics of steel slag treatment line

1. It can crush, magnetic separation, separate and grind the slag produced in the process of converter steelmaking.

2. The remaining coarse particles can be used as the "bone" material of highway pavement. The fine steel slag powder is milled to select iron concentrate powder. The rest is used as high activity admixture of cement and concrete. The slurry washed down by water can also produce steel slag brick.

3. Steel slag and primary slag steel are used as raw materials. Adopt a set of closed cycle production process. After screening. Four kinds of products with high efficiency, high quality and high added value are obtained.
